Формиране на тъкани за изработка на хартия

Qingdao Star Machinery Co., Ltd., предоставя висококачествени формиращи тъкани за индустрия за създаване на хартия, включително видове от 4 до 24 навеси и структури от единични до трислойни структури. Нашите тъкани отговарят на изискванията на различни видове хартия и хартиени машини. Нашите продукти ще бъдат вашият безопасен избор.

Изпратете запитване

Описание на продукта

Qingdao Star Machine specializes in providing high premium Forming Fabrics fabrics for Paper industry. Our Forming Fabrics are a key part of the paper industry process, with four sheds, five sheds, eight sheds, 16 sheds and 24 sheds of various weaving types, ensuring versatility of the products to meet diverse production needs.

In the realm of Forming Fabrics for Paper Making, according to the structure, can be divided into single layer, double layer, two and a half layer, three layers of fabric, each layer is suitable for specific paper making requirements.

Among these, the standard 4-shed and 5-shed single layer paper Forming Fabrics excel in producing a variety of types of paper, from cultural paper to printed paper, glazed paper, wrapping paper and common newsprint. These fabrics are designed to be compatible with common fourdrinier paper machines, ensuring optimum performance and efficiency.

For applications demanding high-quality packing paper such as craft paper, cardboard, and corrugated paper, our 8-shed single layer Forming Fabrics for Paper Making offer unmatched reliability. Similarly, our 8-shed double layer plastic paper are ideal for producing high quality printing paper, including dictionary paper, offset paper, newsprint and wrapping paper to meet the strict requirements of various paper machines.

Our 16-layer, two-layer, semi-plastic paper machine provides first-class performance in the production of high quality printing paper such as offset paper, copperplate paper, newsprint and cigarette paper (wrapping paper and filter paper). These fabrics, suitable for medium and high speed paper making machines, ensure superior results in diverse paper applications.

Finally, the company's three-layer Forming making SSB machine stands out for its ability to produce high-quality printed paper, paper towels and cigarette paper, among other specialty paper products. The design is compatible with high-speed paper making machine, and these Forming Fabrics guarantee superior performance and reliability, making them the first choice to require paper making process. Trust Qingdao Star Machine for Forming Fabrics can optimize your paper work and ensure the high quality and efficiency of the whole production process.

Product Parameter

Forming Fabrics for Paper Making

Weaving Series & Types	Wire Diameter(mm)		Density(wire/cm)		Strength(N/cm)	Air Permeability (m3/m2h)
Weaving Series & Types	Warp	Weft	Warp	Weft	Area of the surface	Air Permeability (m3/m2h)
4-shed single layer fabric	0.20	0.25	29	22	≥600	7500±500
	0.20	0.27	30	22.5	≥600	7600±500
	0.20	0.22	35	28	≥600	6500±500
5-shed single layer fabric	0.20	0.25	30	23	≥600	7600±500
	0.22	0.28	30	23	≥500	7800±500
	0.20	0.21	35	32	≥600	6700±500
8-shed single layer fabric	0.22	0.35	28	19.5	≥700	9000±500
	0.22	0.40	29.5	19	≥700	8500±500
	0.22	0.35	29	20	≥700	8500±500
	0.22	0.40	31.5	19	≥700	8000±500
8-shed double layer fabric	0.17	0.19/0.22	61.3	51.2	≥850	6800±500
	0.18	0.18/0.20	66	49	≥900	6000±500
	0.15	0.16/0.17	70.5	50.5	≥900	5700±500
16-shed two and a half layer fabric	0.28	0.20,0.27/0.50,0.50	37-38	31-32	≥1200	8500±500
	0.25	0.20,0.25/0.45,0.45	48-49	42-43	≥1250	8000±500
	0.18	0.13,0.18/0.25,0.25	57-58	46-47	≥1500	6500±500
	0.20	0.13,0.25/0.35,0.35	56-57	61-62	≥1500	7000±500
	0.18	0.13,0.20/0.25,0.25	62-63	55-56	≥1500	6200±500
	0.20	0.13,0.25/0.35,0.35	61-62	52-53	≥1500	6300±500
20-shed triple layer fabric	0.15,0.20	0.15,0.15/0.35,0.35	70	55	≥1600	5000±500
24-shed triple layer fabric	0.20/0.20	0.20,0.17/0.40,0.40	42	52	≥1600	6500±500

Горещи маркери: Оформяне на тъкани за изработка на хартия, доставчик на хартия за образуване на хартия, образуване на мрежест Китай, плат за хартиена машина
